Forklift Swing Frame Paper Roll Clamp

Paper roll clamp can high efficiency, safety and no damage handle and stack of the roll, and clamp roll to rotate 360 degree continuously, is widely used in paper, carton, packing, printing, ports and other industries of various types of paper roll handling without pallet.

Capacity(kg)	Catalog	Mounting Class	Roll Range (mm)	Long Arm Length (mm)	Short Arm Length (mm)	Arm Thickness (mm)	Vertical Center of Gravity (mm)	Horizontal Center of Gravity (mm)	Effective Thickness (mm)	Weight (kg)
1300	SLZ-A001	2	330-1150	685	515	45	330	216	138	345
1200	SLZ-A002	2	410-1300	790	580	45	330	222	138	345
2000	SLZ-A/B004	2/3	250-1300	824	570	45	345	295/330	210/250	730/748
2000	SLZ-A/B005	2/3	630-1300	824	570	45	345	290/325	210/250	720/738
2000	SLZ-A/B006	2/3	350-1600	956	774	90	345	310/320	210/250	838/848
2000	SLZ-A/B007	2/3	630-1600	956	774	90	345	308/318	210/250	826/834
1700	SLZ-B008	3	680-1830	1130	930	112	345	458	210/250	950
1700	SLZ-B009	3	380-1830	1130	930	112	345	460	210/250	965
2700	SLZ-B/C010	3/4	520-1300	850	590	85	445	270/290	210/250	820/840
2700	SLZ-B/C011	3/4	250-1300	850	590	85	445	270/290	210/250	835/855
2700	SLZ-B/C012	3/4	560-1520	970	690	70	445	305/322	210/250	880/900
2700	SLZ-B/C013	3/4	255-1520	970	690	70	445	305/322	210/250	898/918
2300	SLZ-B/C014	3/4	680-1830	1125	825	88	450	352/372	210/250	995/1016
2300	SLZ-B/C015	3/4	380-1830	1125	825	88	450	352/372	210/250	1018/1040

Note

---

1)Please get the actual comprehensive carrying capacity of forklift/attachment from the forklift factory

2)According to the needs of users, provide splints to adapt to the different requirements of roll holding

3) Requires a forklift to increase the additional 1 sets of oil-way.

Videos

---

Quick Details

---

Place of Origin: Fujian, China (Mainland)
Brand Name:HUAMAI
Product name: swing frame paper roll clamp
Load capacity: 1000~4500 kg
Mounting class: 2~5
Opening range: 200~1830 mm
Long arm length: 685~1130 mm
Short arm length: 515~930 mm
Arm thickness: 45~112 mm
Effective thickness: 138~250 mm
Weight: 345~1040 kg

---

A forklift swing frame paper roll clamp is a type of forklift attachment used for handling and transporting large rolls of paper. The clamp attaches to the forklift and holds the paper rolls in place, allowing the operator to easily pick up, move, and place the rolls.

The swing frame paper roll clamp consists of a frame that attaches to the forklift and a clamp mechanism that holds the rolls in place. The frame is designed to swing back and forth, allowing the operator to adjust the position of the rolls for easier handling. The clamp mechanism is designed to securely hold the rolls in place, reducing the risk of injury and damage to the load and the environment.

One of the main advantages of the forklift swing frame paper roll clamp is its versatility. It can handle a wide range of large rolls of paper, making it a convenient accessory for a variety of material handling tasks. The swing frame also makes it easier to transport the rolls, reducing the risk of injury to the operator and other workers.

Another advantage of the forklift swing frame paper roll clamp is its efficiency. The clamp makes it easier to handle and transport the rolls, reducing the time and effort required to complete the task. This makes it more cost-effective and time-efficient, saving companies time and money in the long run.

In conclusion, the forklift swing frame paper roll clamp is a useful tool for handling and transporting large rolls of paper. It is versatile, efficient, and cost-effective, and is an essential tool for companies that handle heavy loads on a regular basis.
