Material Shovel for Forklift

Application

---

Material Shovel can be used for steel and aluminum smelting company can achieve long-range, high-temperature environment of security operations.

Features

---

Hydraulic system: hydraulic motor with a well-known foreign company's products; Rotary Manifold Seals are imported in the company's products.
Structural parts: the slewing bearing slewing bearings with large modulus, the load capacity; worm and worm involute tooth profile, can improve efficiency, reduce heat loss, but also to achieve self-locking feature.
Mechanical performance: the rotation of hydraulic oil on the road with two-way self-locking, ensuring safety at work.

Note

---

①Obtain the actual capacity of the forklift and attachments from the forklift manufacturer,
②One/Two sets additional oil circuit required on forklift
③Please contact the sales from HUAMAI

Hydraulic Flow & Pressure

---

Model	Min.Hydraulic Flow(L/min)	Rec. Hydraulic Flow(L/min)	Max.Hydraulic Flow(L/min)	Min. Hydraulic Pressure(Bar)	Max. Hydraulic Pressure(Bar)
LMS**G	20	40	60	35	160

 Rotator Specification

---

Model	Rotator Speed	Rotator Torque
LMS**G	4.1r/min@57L/min	9000N.M@160Bar

Options

---

Custom opening ranges
Positioned short arm or fixed short arm
Split long arm
Special pads, Rubber pad, Polyurethane pad

Application:

Handling loose and free-flowing material like dry sand, stones, salt, fertilizer, dry chemicals, grain, etc.

Features and benefits:

Shovel is constructed from 6 mm steel plate.
Loading edge is sharp, straight line or toothed.
Dumping cylinders are enclosed for protection.
Mounting / removal is easy, with just 3 bolts.
Shovel has a 300 forward tilt to ensure full discharge of load.
Full control on shovel movement ensures dumping at desired rate.
